Applicable Product

AES Battery Energy Storage System Cabinets

Unit Model Number

SLL03C2-D1P52S1R4-A01

SLL03C2-D1P52S1R5-A01

SLL03C2-D1P52S1R6-A01

SLL03C2-D1P52S1R7-A01

SLL03C2-D1P52S1R8-A01





Model

212-CAB

266-CAB

318-CAB

372-CAB

426-CAB

Chemistry

LiFePO4 (LFP)

Configuration

208S1P

(4 packs @ 52S1P)

260S1P

(5 packs @ 52S1P)

312S1P

(6 packs @ 52S1P)

364S1P

(7 packs @ 52S1P)

416S1P

(8 packs @ 52S1P)

Nominal Energy

213 kWh

266 kWh

318 kWh

372 kWh

426 kWh

Usable Energy

209 kWh

261 kWh

313 kWh

366 kWh

418 kWh

Nominal Capacity

320 Ah

Usable Capacity

314 Ah

Voltage Range

582.4 -
738.4 V

728 -
923 V

873.6 -
1107.6 V

1019.2 -
1292.2 V

1164.8 -
1476.8 V

Maximum Continuous Current

157 A
