Location and Site Preparation

General Installation Requirements

  • Foundation Stability: The system must be installed on a level, solid foundation capable of supporting the full weight of the battery cabinet when fully loaded with battery packs. Ensure the surface can handle vibration without compromising stability.

  • Accessibility: Clear space around the system for ventilation, cooling, and maintenance. Follow relevant, local installation standards for safety and compliance.

Outdoor Installation Requirements

  • Flood Protection: The installation location should be kept away from flood zones, drainage areas, or regions prone to standing water.

  • Foundation Drainage: Construct the foundation with drainage, sloping away from the system to prevent water pooling near the cabinet base. A slope of at least 3% is recommended.


  • Environmental Safety: Fencing and lighting are recommended for enhanced security, particularly for public or commercial installations. Fencing and lighting may also be required to comply with applicable local regulations.
